FingerTech Spark 20:1 Gearmotor
These custom engineered robot drive motors are designed to handle the rigor of combat without breaking, and they won't hurt your wallet either!

$18.99

Motors
Spark Motors

Click photo to enlarge.

FingerTech Spark 20:1 Gearmotor
Part# 0-FT-SPARK16-20

Please see this product on the new Robot MarketPlace web site. Click here

These are what your robots have been waiting for. These custom engineered robot drive motors are designed to handle the rigor of combat without breaking, and they won't hurt your wallet either! These motors make it super simple to get a robot moving! Just pick up a pair of Lite Flite wheels and Lite Hubs to mount them, solder on a pair of tinyESCs and your motors are ready to go!

Features
The extra-long 3mm shaft is triple-supported internally so that wheels can be mounted directly.
Having the same face mount pattern as the now-obsolete BaneBots 16mm gearmotors means they can be a direct drop-in replacement for all your combat-worn BaneBots motors.
Spur gear reduction motor with mabuchi FK-050 motor.
Several different gear ratios of 20:1, 35:1, 50:1, 63:1, 86:1, 115:1, 150:1, 250:1 and 360:1
At only 28grams (0.99oz), these are a lightweight and still powerful motor.

Motor Specs - Mabuchi FK-050 motor without gearbox
Operating Voltage	4.5V-22.2V (>7.4V decreses motor life)
Nominal Voltage	6V DC
No Load RPM	11530 RPM
No Load Current	0.05A
Stall Current	1.3A
Stall Torque	0.0461 kg-cm (0.64 oz-in.)
Kt	0.0352 kg-cm (0.49 oz-in.)
Kv	1573 rpm/V
Efficiency	52%
RPM at Peak Efficiency	9100
Current at Peak Efficiency	0.34A
Gearbox Specs
Output RPM (at 6V)	472 RPM
Output Torque (at 6V)	10.48 oz-in (755 g-cm)
Physical Specs
Gearbox Length	11.6mm (0.455in.)
Total Length	40.3mm (1.59in.)
Gearbox Diameter	15.5mm (0.61in.)
Shaft Diameter	3mm (0.12in.) with flat along length
Shaft Length	38mm (1.5in.)
Mounting Holes	2; #2-56 spaced 11mm apart
Weight	28g (0.99oz)

Note - Do not stall this motor! you will damage the output gear stage!

Click here to add your own review or comment for this product.

6/7/2011

Evan Steeves

the spark 20:1 motors are some of the best gearmotors I have ever used.

so far I have used them in 3 different antweight robots ranging from a lifter an overhead bar spinner to a full body spinner and now a drum spinner.

I recomend cleaning them after every competetion or 30 minutes of use. this entails removing the gearhead and cleaning out the gears with denatured alcahol or a similar product and waiting until it is completly dry then relubricating with a high speed bushing oil for brushed motors as all gears ride on brass stages
(the gears are steel not brass)

3/1/2011

D.W. Robots

Small and Mighty

The Spark motors are a great choice for drive motors in an antweight robots, but be sure to have the drive wheels protected.

After the first gear in the gearbox, the shaft narrows down to approximately 1.5mm and tends to fail at that location with one or two direct hits to a wheel.
