VEX-CHAN-121-35 VEX Robotics Metal C-Channel 1x2x1x35 Holes, 2-pack <p><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">VEX C-channel has holes on 0.500" increments. This structural member is perfect for building bigger robots. Excellent strength and twist resistance. Can be cut on 2.500" increments. Made from cold rolled steel, 0.046" thick, zinc plated. Includes two (2) lengths of 17.50in. </font></p>
<table width="100%" border="1" cellspacing="0" cellpadding="0">
<tr>
<td colspan="2"><font color="cccccc" size="2" face="Arial, Helvetica, sans-serif">Technical Info </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Metal Type </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Cold Rolled Steel per ASTM A-1008 CS Type B (approx 40ksi tensile strength)</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Metal Thickness </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">0.046in.</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Finish</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Zinc Plated </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Hole Size </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">0.182 square (VEX standard) </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Cuttable</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Each channel is segmented into cuttable 2.5" pieces</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Length</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">17.50 in. </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Weight</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">0.361 lbs </font></td>
</tr>
</table>

VEX Robotics Metal C-Channel 1x2x1x35 Holes, 2-pack
This structural member is perfect for building bigger robots.

$8.99
Robot MarketPlace - VEX Robotics Metal C-Channel 1x2x1x35 Holes, 2-pack

Robot Kits
    VEX Structure


Click photo to enlarge.

VEX Robotics Metal C-Channel 1x2x1x35 Holes, 2-pack
Part# VEX-CHAN-121-35




Please see this product on the new Robot MarketPlace web site. Click here
