The Power 160 is designed to deliver clean and quiet power equivalent to or surpassing the power of a 160-size 2-stroke glow engine for sport and scale airplanes weighing 12-20 pounds, 3D airplanes up to 15 pounds, or models requiring up to 2700 watts of power.
| Type |
Brushless Outrunner |
| Size |
Equivalent to or surpassing the power of a 160-size 2-stroke glow engine |
| Bearins or Brushings |
Ball Bearings |
| Recommended Prop Range |
18x8 to 20x10 |
| Voltage |
33.3-38.4 |
| RPM/Volt (Kv) |
245 |
| Resistance |
0.03 ohms |
| Idle Current |
1.45A at 10V |
| Shaft Diameter |
0.30 in (8mm) |
| Overall Length |
2.50 in (64mm) |
| Weight |
650g (23.0 oz) |
| Overall Diameter |
2.50 in (63mm) |
| Continuous Current |
60A |
| Maximum Burst Current |
78A for 15 seconds |
| Cells |
9-10S LiPoly or 28-32 Nicad/NiMh |
| Speed Control |
85-110A High Voltage Brushless |
Needed to Complete
| 85-110A High Voltage Brushless ESC |
| 9-10S LiPoly or 28-32 NiCad/NiMh |
| 18x8 to 20x10 |
|
